# K9s - Kubernetes CLI To Manage Your Clusters In Style! K9s provides a curses based terminal UI to interact with your Kubernetes clusters. The aim of this project is to make it easier to navigate, observe and manage your applications in the wild. K9s continually watches Kubernetes for changes and offers subsequent commands to interact with observed resources. --- [](https://goreportcard.com/report/github.com/derailed/k9s) [](https://travis-ci.com/derailed/k9s) [](https://github.com/derailed/k9s/releases) [](https://github.com/mum4k/termdash/blob/master/LICENSE) --- ## Installation K9s is available on Linux, OSX and Windows platforms. * Binaries for Linux, Windows and Mac are available as tarballs in the [release](https://github.com/derailed/k9s/releases) page. * For OSX using Homebrew ```shell brew tap derailed/k9s && brew install k9s ``` * Building from source K9s was built using go 1.12 or above. In order to build K9 from source you must: 1. Clone the repo 2. Set env var *GO111MODULE=on* 3. Add the following command in your go.mod file ```text replace ( github.com/derailed/k9s => MY_K9S_CLONED_GIT_REPO ) ``` 4. Build and run the executable ```shell go run main.go ``` --- ## The Command Line ```shell # List all available CLI options k9s -h # To get info about K9s runtime (logs, configs, etc..) k9s info # To run K9s in a given namespace k9s -n mycoolns # Start K9s in an existing KubeConfig context k9s --context coolCtx ``` --- ## PreFlight Checks * K9s uses 256 colors terminal mode. On `Nix system make sure TERM is set accordingly. ```shell export TERM=xterm-256color ``` --- ## K9s config file ($HOME/.k9s/config.yml) K9s keeps its configurations in a dot file in your home directory. > NOTE: This is still in flux and will change while in pre-release stage! ```yaml k9s: # Indicates api-server poll intervals. refreshRate: 2 # Indicates log view maximum buffer size. Default 1k lines. logBufferSize: 200 # Indicates how many lines of logs to retrieve from the api-server. Default 200 lines. logRequestSize: 200 # Indicates the current kube context. Defaults to current context currentContext: minikube # Indicates the current kube cluster. Defaults to current context cluster currentCluster: minikube # Persists per cluster preferences for favorite namespaces and view. clusters: cooln: namespace: active: coolio favorites: - cassandra - default view: active: po minikube: namespace: active: all favorites: - all - kube-system - default view: active: dp ``` --- ## Key Bindings K9s uses aliases to navigate most K8s resources. | Command | Result | Example | |-----------------------|----------------------------------------------------|----------------------------| | `:`alias`` | View a Kubernetes resource | `:po` | | `?` | Show keyboard shortcuts and help | | | `Ctrl-a` | Show all available resource alias | select+`` to view | | `/`filter`ENTER`> | Filter out a resource view given a filter | `/bumblebeetuna` | | `` | Bails out of command mode | | | `d`,`v`, `e`, `l`,... | Key mapping to describe, view, edit, view logs,... | `d` (describes a resource) | | `:`ctx`` | To view and switch to another Kubernetes context | `:`+`ctx`+`` | | `:q`, `Ctrl-c` | To bail out of K9s | | --- ## Demo Video 1. [K9s Demo](https://youtu.be/k7zseUhaXeU) ## Screenshots 1. Pods 1. Logs 1. Deployments --- ## Known Issues This initial drop is brittle. K9s will most likely blow up... 1. You're running older versions of Kubernetes. K9s works best Kubernetes 1.12+. 1. You don't have enough RBAC fu to manage your cluster (see RBAC section below). --- ## K9s RBAC FU On RBAC enabled clusters, you would need to give your users/groups capabilities so that they can use K9s to explore Kubernetes cluster. K9s needs minimaly read privileges at both the cluster and namespace level to display resources and metrics. These rules below are just suggestions. You will need to customize them based on your environment policies. If you need to edit/delete resources extra Fu will be necessary. > NOTE! Cluster/Namespace access may change in the future as K9s evolves. > NOTE! We expect K9s to keep running even in atrophied clusters/namespaces. Please file issues if this is not the case! ### Cluster RBAC scope ```yaml --- # K9s Reader ClusterRole kind: ClusterRole apiVersion: rbac.authorization.k8s.io/v1 metadata: name: k9s rules: # Grants RO access to cluster resources node and namespace - apiGroups: [""] resources: ["nodes", "namespaces"] verbs: ["get", "list", "watch"] # Grants RO access to RBAC resources - apiGroups: ["rbac.authorization.k8s.io"] resources: ["clusterroles", "roles", "clusterrolebindings", "rolebindings"] verbs: ["get", "list", "watch"] # Grants RO access to CRD resources - apiGroups: ["apiextensions.k8s.io"] resources: ["customresourcedefinitions"] verbs: ["get", "list", "watch"] # Grants RO access to netric server - apiGroups: ["metrics.k8s.io"] resources: ["nodes", "pods"] verbs: ["list"] --- # Sample K9s user ClusterRoleBinding apiVersion: rbac.authorization.k8s.io/v1 kind: ClusterRoleBinding metadata: name: k9s subjects: - kind: User name: fernand apiGroup: rbac.authorization.k8s.io roleRef: kind: ClusterRole name: k9s apiGroup: rbac.authorization.k8s.io ``` ### Namespace RBAC scope If your users are constrained to certain namespaces, K9s will need to following role to enable read access to namespaced resources. ```yaml --- # K9s Reader Role (default namespace) kind: Role apiVersion: rbac.authorization.k8s.io/v1 metadata: name: k9s namespace: default rules: # Grants RO access to most namespaced resources - apiGroups: ["", "apps", "autoscaling", "batch", "extensions"] resources: ["*"] verbs: ["get", "list", "watch"] --- # Sample K9s user RoleBinding apiVersion: rbac.authorization.k8s.io/v1 kind: RoleBinding metadata: name: k9s namespace: default subjects: - kind: User name: fernand apiGroup: rbac.authorization.k8s.io roleRef: kind: Role name: k9s apiGroup: rbac.authorization.k8s.io ``` --- ## Skins You can style K9s based on your own sense of style and look. This is very much an experimental feature at this time, more will be added/modified if this feature has legs so thread accordingly! Skins are YAML files, that enable a user to change K9s presentation layer. K9s skins are loaded from `$HOME/.k9s/skin.yml`. If a skin file is detected then the skin would be loaded if not the current stock skin remains in effect. Below is a sample skin file, more skins would be available in the skins directory, just simply copy any of these in your user's home dir as `skin.yml`. ```yaml # InTheNavy Skin... k9s: # General K9s styles fgColor: dodgerblue bgColor: white logoColor: blue # ClusterInfoView styles. info: fgColor: lightskyblue sectionColor: steelblue # Borders styles. border: fgColor: dodgerblue focusColor: aliceblue # MenuView attributes and styles. menu: fgColor: darkblue keyColor: cornflowerblue # Used for favorite namespaces numKeyColor: cadetblue # CrumbView attributes for history navigation. crumb: fgColor: white bgColor: steelblue # Active view settings activeColor: skyblue # TableView attributes. table: fgColor: blue bgColor: darkblue cursorColor: aqua # Header row styles. header: fgColor: white bgColor: darkblue sorterColor: orange # Resource status and update styles status: newColor: blue modifyColor: powderblue addColor: lightskyblue errorColor: indianred highlightcolor: royalblue killColor: slategray completedColor: gray # Border title styles. title: fgColor: aqua bgColor: white highlightColor: skyblue counterColor: slateblue filterColor: slategray # YAML info styles. yaml: keyColor: steelblue colonColor: blue valueColor: royalblue ``` Available color names are defined below: | Color Names | | | | | |----------------------|----------------|------------------|-------------------|-----------------| | black | maroon | green | olive | navy | | purple | teal | silver | gray | red | | lime | yellow | blue | fuchsia | aqua | | white | aliceblue | antiquewhite | aquamarine | azure | | beige | bisque | blanchedalmond | blueviolet | brown | | burlywood | cadetblue | chartreuse | chocolate | coral | | cornflowerblue | cornsilk | crimson | darkblue | darkcyan | | darkgoldenrod | darkgray | darkgreen | darkkhaki | darkmagenta | | darkolivegreen | darkorange | darkorchid | darkred | darksalmon | | darkseagreen | darkslateblue | darkslategray | darkturquoise | darkviolet | | deeppink | deepskyblue | dimgray | dodgerblue | firebrick | | floralwhite | forestgreen | gainsboro | ghostwhite | gold | | goldenrod | greenyellow | honeydew | hotpink | indianred | | indigo | ivory | khaki | lavender | lavenderblush | | lawngreen | lemonchiffon | lightblue | lightcoral | lightcyan | | lightgoldenrodyellow | lightgray | lightgreen | lightpink | lightsalmon | | lightseagreen | lightskyblue | lightslategray | lightsteelblue | lightyellow | | limegreen | linen | mediumaquamarine | mediumblue | mediumorchid | | mediumpurple | mediumseagreen | mediumslateblue | mediumspringgreen | mediumturquoise | | mediumvioletred | midnightblue | mintcream | mistyrose | moccasin | | navajowhite | oldlace | olivedrab | orange | orangered | | orchid | palegoldenrod | palegreen | paleturquoise | palevioletred | | papayawhip | peachpuff | peru | pink | plum | | powderblue | rebeccapurple | rosybrown | royalblue | saddlebrown | | salmon | sandybrown | seagreen | seashell | sienna | | skyblue | slateblue | slategray | snow | springgreen | | steelblue | tan | thistle | tomato | turquoise | | violet | wheat | whitesmoke | yellowgreen | grey | | dimgrey | darkgrey | darkslategrey | lightgrey | lightslategrey | | slategrey | | | | | --- ## Disclaimer This is still work in progress! If there is enough interest in the Kubernetes community, we will enhance per your recommendations/contributions. Also if you dig this effort, please let us know that too! --- ## ATTA Girls/Boys! K9s sits on top of many of opensource projects and libraries. Our *sincere* appreciations to all the OSS contributors that work nights and weekends to make this project a reality! --- ## Contact Info 1. **Email**: fernand@imhotep.io 2. **Twitter**: [@kitesurfer](https://twitter.com/kitesurfer?lang=en) --- © 2019 Imhotep Software LLC. All materials licensed under [Apache v2.0](http://www.apache.org/licenses/LICENSE-2.0)
